Pneumatic parallel two jaw parameters
Name:Pneumatic parallel two claws
Model:FY30ZM-D90
P(bar):Air Pressure(bar)
L:Exertion Length(mm)
Stoke:50mm
Weight:5.72kg
Max.length attach:200mm
Fitting size:PF(G）1/8"
Gripping force:Open::3255N
Gripping force:Close:3048.9N
Air consumption per cycle:305.8cm3
Closeing/Opening time.0.3/0.3sec
Repeat accuracy:0.02mm
Continuation usage amount:30
Operating pressure:3-7bar
Ambient temperature:-5to60℃(-10to130℃)
Lubrication:Needless
Safety protection according to IEC60529 standard:IP64
All data were measured at7Bar
After 100 consecutive strokes to end positions
