Name:Pneumatic 3-claw

Name:Pneumatic parallel three claws

Model:FY46ZM-D200

P(bar):Air Pressure(bar)

L:Exertion Length(mm)

Stoke：60mm

Weight:20.05kg

Max.length attach:355mm

Fitting size):PF(G）1/4"

Gripping force:Open:12540N

Gripping force:Close:12130N

Closeing/Opening time:0.12/0.25sec

Repeat accuracy):0.05mm

Continuation usage amount.:20

Operating pressure:3-8bar

Ambient temperature:-5to60℃(-10 to130℃)

Lubrication:Needless

Safety protection according to IEC60529 standard:IP64

All data were measured at 6 Bar

After 100 consecutive strokes to end positions
