1.Overall dimensions：180X125.5X100

2.Effective clamping stroke：32mm（double acting）

3.DriveCylinder diameterarea：7456.6square millimetre

    Piston rodarea：924square millimetre

4.Clamping force (when the input air pressure is 0.5~1.5MPa)：

    Open：1936.6N(197.6kgf)5809.8N(592.8kgf)

    Closed：1696.6N(173.1kgf)5089.9N(519.4kgf)

Grip the efficiency coefficient：0.85

5.Air tube type： external or built-in(Default external， if they need abuilt-in， can contact us in advance)

6.Opening and closing time：0.3~1.5Sec

7.Working air pressure：0.5~1.5MPa

8.Operating temperature：-5℃~+60C

9.Weight：6.3kg。
