Pneumatic three jaw parameters
Name:Pneumatic parallel three claws
Mode I:FY56N-D80-L
Stoke:2*27=54mm
Weight:3.9kg
Max.length attach.:130mm
Fitting size:PF(G1/8")
Gripping force:Open:3230N
Gripping force:Close:3028N
Air consumption per cycle:163cm3
Closeing/Opening time:0.8/0.8sec
Repeat accuracy.:0.03mm
Continuation usage amount).:60
Operating pressure:3-8bar
Ambient temperature:-5to90℃(-10to130℃)
Lubrication:Needless
EC60529：IP40
Safety protection according to IEC60529 standard:IP40
All data were measured at6Bar
After 100 consecutive strokes to end positions
