1. Size code：50

2.Working fluid: air (without oil) double acting

3.Operating pressure：0.1~1.0MPa

4.Ambient and fluid temperature：-5~60℃

5. Angle adjustment range： 0~190 Degrees

6.Cylinder diameter：25mm

7.Allowable radial load314~378N

8. Allowable axis load：296~451N

9.Allowable bending moment：9.7N.m

10. Effective output torque at 0.5 MPa：4.64N.m

11.Rotation time：0.2~0.8s

12.assembly Weight：6.1kg

1. Size code：50

2.Working fluid: air (without oil) double acting

3.Operating pressure：0.1~1.0MPa

4.Ambient and fluid temperature：-5~60℃

5. Angle adjustment range： 0~190 Degrees

6.Cylinder diameter：25mm

7.Allowable radial load314N~378N

8. Allowable axis load：296N~451N

9.Allowable bending moment：9.7N.m

10. Effective output torque at 0.5 MPa：4.64N.m

11.Rotation time：0.2~0.8s

12.Weight：1.8kg
