Name:Pneumatic paral lel two claws

Model:FY-JGP160-AS

P(bar):Air Pressure(bar)

L:Exertion Length(mm)

Stoke:32mm

Weight:3.55kg

Max.length attach:200mm

Fitting size:PF(G)1/8"

Gripping force:Close:2210N

Air consumption per cycle:157cm³

Closeing./Opening time:0.15/0.15sec

Repeat accuracy:0.01mm

Continuation usage amount.:40

Operating pressure:3-8bar

Ambient temperature:-5to90℃(-10to130℃)

Lubrication:Needless

Safety protection according to IEC60529 standard:IP40

All data were measured at6Bar

After 100 consecutive strokes to end positions
