名稱：氣動寬幅式平行兩爪

Name:Pneumatic thin paral lel two claw

型號(Mode1):FY02-10-20

P:空氣壓力(bar)P:Air Pressure(bar)

L:到作用點距離(mm)L:Exertion Length(mm)

開閉範圍(Stoke):22mm=2*11mm

産品重量(Weight):0.33kg

配管連接口(Fitting size):M5

理論夾持力-(Gripping force(N):56.5N

開閉時間(Closeing/0 pening time):0.05/0.05sec

重複精度（Repeat accuracy):0.1mm

連續使用次數(Continuation usage amount):60

使用氣壓(Operating pressure):3-8bar

周圍溫度(Ambient temperature):-5to60℃(-10to130℃)

潤滑(Lubr ication):不需要(Needless)

根據1EC60529標准安全防護：1P64

Safety protection according to IEC60529 standard:IP64

所有數據在5Bar時測量(AlI data were measured at7Bar)

重複精度：連續動作100次以後的檢測值

After 100 consecutive strokes to end

positions
